2025 Catalina 316
GENERAL DIMENSIONS
Length Overall: 33′ 0″
Length of Hull: 31′ 0″
Length at Waterline: 26’6″
Beam: 11′ 7″
Distance from Waterline to Masthead: 49′ 3″
SHOAL BULB KEEL
Draft: 4′ 9″
Ballast: 4,400 lbs
Displacement – Half Load: 12,400 lbs
FIN KEEL
Draft: 6′ 3″
Ballast: 4,000 lbs
Displacement – Half Load: 12,000 lbs
RIG MEASUREMENTS
Total with 100% Foretriangle: 530ft 2
Total with Standard 135% Genoa: 589ft 2
I= 42′ 9″
J= 12′ 0″
P= 40′ 3″
E= 13′ 6″
TANKS & CAPACITIES
Water: Forward 35 gal
Water Heater: 6 gal
Total Water: 41 gal
Sanitary Holding Tank: 17 gal
Fuel: 25 gal
ENGINE & CONTROLS
Yanmar 3YM20, 21 HP Diesel
Pedestal Steering with 40″ Stainless Wheel
Single Lever Engine Controls
3 Blade Dynajet 14 x 2
WINDLASS & CHAIN
Quick Genius 600
1/4″ High Test or BBB Chain
WINCHES
Primary Lewmar #40, Chrome Bronze, Evo Self Tailing
Secondary Lewmar #30, Chrome Bronze, Evo Self Tailing
ELECTRICAL
Batteries: Qty-2 4D 150 Amp-Hrs
Shore Power: Qty-1. 30 Amp Service
Battery Charger: Qty-1 20Amp
